Thinvent® Neo H Mini PC, Intel® processor N5095A (4 core, up to 2.9 GHz, 4 MB cache), 4GB DDR4 RAM, 128GB SSD, 12V 5A Adapter, No WiFi, Windows 11 IoT
SKU: H-N5-4-m128-12_5-X-11I-0
Ready in 3 days: 11 units
Ready in 15 days: 42 units
Engineered for the relentless rhythm of industry: meet the Neo H.
Specifications
Processing
| Generation | 11th |
| Series | Celeron |
| Processor Brand | Intel |
| Processor Model | N5095A |
| Cores | 4 |
| Max Frequency | 2.9 GHz |
| Cache | 4 MB |
| Main Memory | 4 GB |
| SSD Storage | 128 GB |
Display
| HDMI | 1 |
| VGA | 1 |
Audio
| Speaker Out | 1 |
| Mic In | 1 |
Connectivity
| USB 3.0 | 4 |
Networking
| Ethernet | 1000 Mbps |
Power
| DC Voltage | 12 Volts |
| DC Current | 5 Amps |
| Power Input | 100~240 Volts AC, 50~60 Hz, 1.5 Amps maximum |
| Cable Length | 2 Metre |
Environmental
| Operating Temperature | 0°C ~ 40°C |
| Operating Humidity | 20% ~ 80% RH, non condensing |
| Certifications | BIS, RoHS, ISO |
Physical
| Form Factor | Mini PC |
| Dimensions | 210mm × 202mm × 80mm |
| Packing Dimensions | 340mm × 235mm × 105mm |
| Housing Material | Steel |
| Housing Finish | Powder Coated |
| Housing Colour | Black |
| Net and Gross Weight | 1.58kg, 2.00kg |
Operating System
| Operating System | Microsoft Windows 11 IoT Enterprise LTSC 2024 Entry |
Where rugged reliability meets serious computing power. As the high-performance heart of our bestselling Neo series, this industrial workhorse is built from the ground up for demanding environments. It’s not just a computer; it’s the dependable core for your critical control systems.
Built for the long haul
- Experience unwavering stability for industrial automation, machine control, and digital signage.
- Hosted in a solid, powder-coated steel chassis for superior durability and heat dissipation.
- Benefit from a wealth of connectivity with multiple USB 3.0 and legacy ports for seamless integration.
- Deploy with absolute confidence, backed by robust Indian design and manufacturing.
The Neo H delivers steadfast performance where it matters most. It’s the robust, reliable foundation your industrial applications deserve.
